ENERGY SAVING AND ECO-SUSTAINABILITY
- exclusive invisible flanging system
- elimination of the longitudinal leaks and reduction of the ones in the transversal junctions
- “C” air seal class according to the UNI EN 13403 standard
- high thermal insulation with a thermal conductivity value of λi=0,022 W/(m °C) measured at 10 °C
- maximum utilization of the AHU performance and and increase in the whole systems efficiency
- ecological water foaming expansion (Hydrotec) without the use of green house effect gasses
- LCA (Life Cycle Assessment) study of the duct
- Environmental Product Declaration (EPD)
- Concrete contribution to the LEED score
SAFETY
- compliance with the principal International safety standards
- class B according to EN 13501-1
- excellent performance to the most demanding tests (ISO 9705 – Room Corner Test)
- reduced smoke emissions
- low toxicity and opacity of the fumes (F1 class according to AFNOR NF F 16-101)
- lightness and rigidity
- deformation and movement reduction
- high dampening values
HYGIENE AND AIR QUALITY
- internal aluminium surface which eliminates the particle release problem
- high level of hygiene guaranteed by the aluminium, which is suitable for the food industry
- no contribution from the material to the proliferation of the bacteria
- availability of panels with antimicrobial treatment and self-cleaning effect
CONSTRUCTION ADVANTAGES
- transportation ease
- possibility to quickly bring about changes also on site
- construction equipment studied on purpose
- coded construction procedures
- extremely reduced weight compared to sheet metal ducts
- reduction of the load on the bearing structure
- reduction of the bracketing points
- reduction of labour time needed for the installation
The self-cleaning solution (P3ductal careplus) is capable of reducing the accumulation of dust and solid particles during the following phases:
- initial start-up testing
- movement of duct sections
- flsh-out Phase (LEED – IAQ management plan)
OTHER TECHINCAL ADVANTAGES
high acoustic comfort thanks to a good linear attenuation especially at low frequencies- vibrations and resonance blocked by the insulating panel
- strength, rigidity and good resistance to corrosion, erosion and deformation
